Uniview KIT-104LSW-4F40 Uniarch

composto da: NVR-104LS-W + 4 Telecamere IPC-B112-F40W Wi-FI
415,80 €
Disponibile
SKU
KIT-104LSW-4F40
Brand
Uniview
Tempi di spedizione
da 2 a 6 giorni lavorativi

UNIVIEW KIT-104LSW-4F40 UNIARCH Wifi, Composto da NVR 4 Canali 2 MP WI-FI  Ultra 265, 4 Bullet  IPC-B112-F40W Wifi 2MP 4 mm



NVR-104LS-W

  • Modulo Wi-Fi integrato ad alte prestazioni e alta stabilità
  • Supporta la crittografia CCMP e l'autenticazione WPA2-PSK, supporta le telecamere IP con accesso Wi-Fi
  • Supporta i formati video Ultra 265 / H.265 / H.264
  • Ingresso a 4 canali
  • Telecamere IP di terze parti supportate con conformità ONVIF: Profilo S, Profilo G, Profilo T
  • Supporta HDMI a 1 canale, VGA a 1 canale
  • Sono fornite uscite sincrone HDMI e VGA
  • Registrazione con risoluzione fino a 5 MP
  • 1 HDD SATA, fino a 6 TB per ogni HDD
  • Supporta l'aggiornamento cloud

IPC-B112-F40W

  • Funzionalità giorno / notte
  • Smart IR, distanza IR fino a 30 m (98 piedi)
  • Finestra in vetro ottico con maggiore trasmissione della luce
  • Finestra IR antiriflesso per aumentare la trasmittanza infrarossa
  • 2D / 3D DNR (riduzione digitale del rumore)
  • Ultra 265, H.265, H.264
  • ROI (regione di interesse)
  • IEEE802.11b / g / n
  • 2,4 GHz ~ 2,4835 GHz
  • Conformità ONVIF
  • Ampio intervallo di temperatura: -30 ° C ~ + 60 ° C (-22 ° F ~ 140 ° F)
  • Ampio intervallo di tensione di ± 25%
  • IP67
ModelNVR-104LS-W
Video/Audio Input
IP Video Input4-ch
Network
Incoming Bandwidth40Mbps
Outgoing Bandwidth40Mbps
Remote Users128
ProtocolsP2P, UPnP, NTP, DHCP, PPPoE
Video/Audio Output
HDMI/VGA OutputHDMI:
1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz
VGA:
1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz
Recording Resolution5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
Audio Output1-ch, RCA
Synchronous Playback4-ch
Corridor Mode Screen3/4
Decoding
Decoding formatUltra 265/H.265/H.264
Live view/ Playback5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
Capability1 x [email protected], 2 x [email protected], 2 x [email protected],4 x [email protected]
Hard Disk
SATA1 SATA interface
CapacityUp to 10TB for each HDD
External Interface
Network Interface1 RJ45 10M/100M self-adaptive Ethernet Interface
USB InterfaceRear panel:2 x USB2.0
Wi-Fi
Frequency2.4GHz
Transmission Rate150Mbps
Wireless StandardsIEEE 802.11b/g/n
Wireless Range280m(open environment)
General
Power Supply12V DC
Power Consumption: ≤ 9 W( without HDD )
Working Environment-10°C ~ + 55°C ( +14°F ~ +131°F ), Humidity ≤ 90% RH(non-condensing)
Dimensions(W×D×H)205mm × 205mm × 46mm (8.1" ×8.1"×1.8")
Weight ( without HDD )

≤0.58Kg(1.28lb)



ModelIPC-B112-F40W
Sensor1/2.9", 2.0 megapixel, progressive scan, CMOS
Lens[email protected]
DORI DistanceLensDetect(m)Observe(m)Recognize(m)Identify(m)
4mm64.325.712.96.4
Angle of view(H)82.0°
Angle of View (V)41.4°
Angle of View (O)100.9°
ShutterAuto/Manual, 1~1/100000 s
Minimum IlluminationColour: 0.02 Lux (F2.0 AGC ON)
0 Lux with IR on
Day/NightIR-cut filter with auto switch (ICR)
Digital noise reduction2D/3D DNR
S/N>52dB
IR RangeUp to 30m (98 ft) IR range
Wavelength850nm
IR On/Off ControlAuto/Manual
DefogDigital Defog
WDRDWDR
Video
Video CompressionUltra 265, H.265, H.264
H.264 code profileBaseline profile, Main Profile
Frame RateMain Stream:2MP (1920×1080): Max. 20 fps;
Sub Stream: 720P (1280×720): Max. 20 fps;
Video Bit Rate128 Kbps~6 Mbps
OSDUp to 4 OSDs
Privacy MaskUp to 4 areas
ROIUp to 2 areas
Motion DetectionUp to 4 areas
White BalanceAuto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
Digital noise reduction2D/3D DNR
Smart IRSupport
FlipNormal/Vertical/Horizontal/180°
DewarpingNA
HLCSupported
BLCSupported
Network
ProtocolsIPv4, IGMP, ICMP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, UPnP, HTTP
Compatible IntegrationONVIF (Profile S, Profile T), API
ClientEZStation
EZView
EZLive
Web BrowserIE: IE8; IE9; IE11
Chrome
Firefox
Edge
Safari
Wi-Fi
Wireless StandardsIEEE802.11b/g/n
Frequency Range2.4 GHz ~ 2.4835 GHz
Channel Bandwidth20 MHz Support
Modulation Mode802.11b: CCK, QPSK, BPSK
802.11g/n: OFDM/HT
Security64/128-bit WEP, WPA-PSK/WPA2-PSK
Transmit Power802.11b: 17±[email protected]
802.11g: 14±[email protected]
802.11n: 12.5±[email protected]
Receive Sensitivity802.11b: [email protected] (Typical)
802.11g: [email protected] (Typical)
802.11n: [email protected] (Typical)
Transmission Rate802.11b: 11Mbps
802.11g: 54Mbps
802.11n: up to 150Mbps
Interface
Network1 RJ45 10M/100M Base-TX Ethernet
Certifications
CertificationsCE(EN 60950-1:2006)
UL:UL60950-1
FCC:FCC Part 15
General
PowerDC 12V±25%
Power consumption: Max 4 W
Dimensions (L × W × H)168.4 × 66.5 × 62.5mm (6.6” × 2.6” × 2.5”)
Weight0.25 kg (0.55 lb)
MaterialFront cover:metal
Body:plastic
Bracket:plastic
Bottom plate:plastic
Working Environment-30°C ~ +60°C (-22°F ~ 140°F), Humidity: ≤95% RH(non-condensing)
Storage Environment-40°C ~ 70°C (-40°F ~ 158°F), Humidity: ≤95% RH (non-condensing)
Ingress ProtectionIP67
Reset ButtonSupported



Maggiori Informazioni
Sottotitolo composto da: NVR-104LS-W + 4 Telecamere IPC-B112-F40W Wi-FI
Brand Uniview
Tempi di spedizione da 2 a 6 giorni lavorativi
Tecnologia IP Uniview
Canali 4 Canali
